Gagemaker Thread Disk for Windows®, 2 Users Software Program, Digital Download 2 Email Addresses Required

The Thread Disk™ engineering software (TDWin™ ) calculates critical dimensions for threads based on ANSI tables and formulas. Thread types supported by the program include: UN, UNJ, and UNR Series, Acme, Stub Acme, Stub Acme Modified I and II, Metric M & MJ, 7° X 45° Buttress, and General Purpose Pipe Threads. To generate critical dimensions instantly, enter basic thread information on the Thread Type Entry screen, such as: thread type, thread class, nominal diameter, and threads per inch. Once the results are computed, tabs at the bottom of the program allow selection of several types of calculated information, including dimensions and tolerances for product threads, ring gages, set plugs, plug gages, or Gagemaker’s Thread Diameter gages. If measuring internal and external shallow taper diameters is a problem, the Ball mic SET DIM Tool provides setting dimensions for ball micrometers or Gagemaker’s BX-1000 groove gage. The program calculates ball mic settings for any tapered surface geometry. Other program features include the ability to print thread dimension reports, which provide a paper copy of any calculation. These reports provide the same critical dimensions that are displayed in the program. A multiple calculation window capability allows performing several different thread calculations at the same time.
