Thread Disk for Windows®, 15 Users Multi-user Software Program, Digital Download 15 Email addresses required to purchase.

The Thread Disk™ engineering software (TDWin™ ) calculates critical dimensions for threads based on ANSI tables and formulas. Thread types supported by the program include: UN, UNJ, and UNR Series, Acme, Stub Acme, Stub Acme Modified I and II, Metric M & MJ, 7° X 45° Buttress, and General Purpose Pipe Threads. To generate critical dimensions instantly, enter basic thread information on the Thread Type Entry screen, such as: thread type, thread class, nominal diameter, and threads per inch. Once the results are computed, tabs at the bottom of the program allow selection of several types of calculated information, including dimensions and tolerances for product threads, ring gages, set plugs, plug gages or Gagemaker’s Thread Diameter gages. If measuring internal and external shallow taper diameters is problematic, the Ball mic SET DIM Tool sets dimensions for ball micrometers or Gagemaker’s BX-1000 groove gage. The program calculates ball mic settings for any tapered surface geometry. Other features of the program include the ability to print thread dimension reports, which provide a paper copy of any calculation. These reports provide the same critical dimensions that are displayed in the program. A multiple calculation window capability allows performing several different thread calculations at the same time.
